Inverter Driven Water to Water Heat Pump
GeoSmart’s NetZero Basic range of ground source heat pumps allows you to reduce up to 80% of the energy consumption of a home, using a renewable source of energy that minimizes the CO2 emissions to the environment.
Our R&D department, after several years of development, was able to produce a very compact and easy to install heat pump keeping on it all the controls necessary to regulate your house temperature. Thanks to the inverter technology and NetZero controls strategies, the water to water heat pump is the most versatile and intelligent available in the market. Unlike traditional heat pumps, the NetZero adapts to the needs of the installation.
Technical Characteristics
Power: 1-9 kW / 3-12 kW / 5-22 kW
COP: 4.6 / 4.9
Refrigerant: R410A
Power supply: Single-phase 230V-60 Hz
Weight: 185-193 Kg
Noise level: 35 to 46 dB
Applications: Heating, DHW, Active and Passive Cooling, Pool/Spa Heating
Features & Benefits
- Carel inverter technology
- Copeland scroll compressor
- Electronic expansion valve
- Integrated variable speed circulator pumps
- Alfal Lavel asymmetrical plate hx
- pCOOEM+ Carel control
- Active heating and cooling
- Passive cooling (optional) and Pool/Spa heating
- 3-way valve for heat/DHW generation
- DHW via patented HTR technology
- Built-in noise insulation kit
- Easynet WiFi internet connectivity
- Built-in energy meters
- Integrated cascade control of up to 3 units
- Ground-Source, Aerothermal-Source, or Hybrid mode
